Belt feeding weighing bagging machine

Belt Feeding Weighing Bagging Machine - Complete English IntroductionBelt Feeding Weighing Bagging Machine – High Precision Automatic Packaging SolutionOur BF-WB Series belt feeding weighing bagging m

Brand：

Model：

Belt Feeding Weighing Bagging Machine - Complete English Introduction

Belt Feeding Weighing Bagging Machine – High Precision Automatic Packaging Solution

Our BF-WB Series belt feeding weighing bagging machine integrates belt conveying, accurate weighing and automatic bagging in one system, which is widely applied in agriculture, chemical and feed industries. This advanced packaging equipment is designed to streamline your production line with exceptional efficiency and reliability.

Key Features:

? Efficient Feeding System: Equipped with stepless speed regulation belt conveyor (0.5–3 m/s) that ensures stable material flow. The customizable belt width (200–600 mm) adapts perfectly to various granular and powdery materials.

? Precise Weighing Technology: Features ±0.2% FS high accuracy with stainless steel anti-corrosion load cell. The dual-range weighing options (5–50 kg / 10–100 kg) provide flexible solutions for different packaging requirements.

? Smart Control System: PLC + touch screen operation enables easy parameter setting and production data tracking. The automatic calibration function ensures consistent weighing performance over time.

? High-Speed Bagging: Achieves 800–1200 bags/hour depending on material and weight. Supports multiple bag types including woven bags, PP bags, and paper bags with lengths from 20–120 cm.

Technical Parameters

Category	Parameters
Basic Model	BF-WB Series (BF-WB50, BF-WB100, etc.)
Feeding System	- Feeding method: Belt conveyor feeding - Belt width: 200–600 mm (customizable) - Conveyor speed: 0.5–3 m/s (stepless speed regulation)
Weighing System	- Weighing range: 5–50 kg / 10–100 kg (dual-range optional) - Accuracy: ±0.2% FS (full scale) - Weighing sensor: Load cell (stainless steel, anti-corrosion) - Control mode: PLC + touch screen, automatic calibration
Bagging System	- Bag type: Woven bag, PP bag, paper bag (20–120 cm bag length) - Bagging speed: 800–1200 bags/hour (depending on material & weight) - Sealing method: Sewing sealing / heat sealing (optional) - Bag clamping: Pneumatic automatic clamping
Material Compatibility	Granular materials (grain, fertilizer, feed, plastic particles), powdery materials (with dust removal device)
Structure & Material	- Frame: Carbon steel (painted) / stainless steel 304 - Protection level: IP54 (dust-proof, splash-proof)
Power & Dimension	- Power supply: 380V/50Hz 3-phase (customizable for 220V/60Hz) - Power: 2.2–7.5 kW - Overall dimension: 2800×1200×3200 mm (L×W×H, customizable) - Net weight: 800–1500 kg
Optional Functions	Dust collector, metal detector, automatic bag stacking machine, data printing system, remote monitoring

Application Industries

Ideal for chemical, agricultural, building materials, and food processing industries. Our belt feeding weighing bagging machine provides reliable packaging solutions for:

Fertilizer and agricultural products
Chemical powders and granules
Animal feed and pet food
Plastic resins and pellets
Construction materials
