2 Nozzles Semi Auto Filling Machine
Guangzhi’s 2-nozzle semi-auto filler achieves 40 containers/min with ±0.5% accuracy. FDA/CE-certified. Doubles output & reduces waste to 0.2%. Free trial!
- Brand： glzon
- Model： GZM_30L
2-Nozzle Semi-Automatic Filling Machine GZ-SF2N Series
*Dual-Channel Precision for Small-Batch Flexibility (50ml–5L Containers)*
Shanghai Guangzhi Automation’s GZ-SF2N Series combines operator-guided simplicity with industrial-grade accuracy, delivering ±0.5% filling precision across liquids, creams, and pastes (1–50,000 cP) via two independent servo-controlled nozzles. Ideal for cosmetics, chemicals, food, and pharmaceuticals, this CE/FDA-compliant system doubles output versus single-nozzle machines while reducing labor costs by 60% and product waste to <0.2%.
Core Innovations
Dual-Channel Efficiency
Independent Servo Pumps: Fill two containers simultaneously (±0.5% accuracy) with adjustable volumes (50ml–5L).
Cross-Contamination Prevention: Dedicated fluid paths (316L SS/PTFE) for each nozzle.
Operator-Optimized Workflow
Foot Pedal + Touchscreen Control: Hands-free activation; preset 30+ recipes (speed/viscosity profiles).
Quick-Change Tooling: Swap nozzles/cylinders for containers (?15–150mm) in <60 seconds (no tools).
Zero-Waste Technology
Vacuum Suck-Back Nozzles: Eliminate drips (residual loss <0.05ml/fill).
Auto-Purge Function: Cleans lines between batches (5-second cycle).
Hygienic & Durable Build
CIP-Ready Design: Removable hopper/drip tray for washdown (IP65 electronics).
ATEX Option: Explosion-proof for solvents (Zone 2/22).
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GZ-SF2N-Pro |
| Filling Range | 50 ml – 5,000 ml (per nozzle) |
| Accuracy | ±0.5% |
| Speed | 20–40 containers/minute (operator-dependent) |
| Viscosity Range | 1–50,000 cP |
| Container Compatibility | Bottles/jars/tubes: ?15–150mm, H30–300mm |
| Power | 220V/50Hz, 1.8 kW |
| Air Supply | 0.5 MPa, 0.15 m3/min |
| Hopper Capacity | 15 L (heated option: 30–80°C) |
| Footprint (L×W×H) | 1000 × 700 × 1600 mm |
| Compliance | CE, FDA 21 CFR, ISO 9001 |
Performance vs. Single-Nozzle Machines
| Metric | GZ-SF2N (Dual Nozzle) | Single-Nozzle Filler |
|---|---|---|
| Output | 40 CPM | 20 CPM |
| Labor Efficiency | 1 operator | 1 operator |
| Product Waste | <0.2% | 0.3–0.8% |
| Changeover Time | 60 seconds | 90 seconds |
| ROI Period | 3–6 months | 6–12 months |
Industry Applications
Cosmetics: Lotions, serums, creams (foam-free filling mode).
Chemicals: Solvents, adhesives (conductive nozzles for static control).
Food: Sauces, oils (USDA-compliant materials).
Pharma: Tinctures, sanitizers (GMP upgrade with laminar hood).
